- Country
- Canada
- Manufacturer / Brand
- Canadian General Electric (Canada) (C.G.E. or CGE); Toronto, ON
- Year
- 1937/1938
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 93514
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superhet with RF-stage; ZF/IF 460 kHz
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast plus 2 Short Wave bands.
- Power type and voltage
- Storage and/or dry batteries / 2.5 & 3 x 45 & 7.5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: F6B - Canadian General Electric
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Notes
-
The "C" battery is tapped for 1.5 and 3 volt.
There is another bias-cell (not specified) for biasing the 1st detector/oscillator 1C6.
- Literature/Schematics (1)
- Radio College of Canada, Individual Circuit Service, 1927-1953
- Literature/Schematics (2)
- Cathedral & Tombstone Radios (page 123.)
- Author
- Model page created by Vitor Oliveira. See "Data change" for further contributors.
- Other Models
-
Here you find 505 models, 373 with images and 428 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Canadian General Electric (Canada) (C.G.E. or CGE); Toronto, ON
