De Luxe

Carad; Kuurne

Data
Forum
Pictures
Collections

  • Year
  • 1967–1970 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 341470
    • Brand: Carpentier, Ets. G.L.

 Technical Specifications

  • Number of Transistors
  • 11
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
  • Power type and voltage
  • Line / Batteries (any type) / AC: 220 / 2 X 4,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Material
  • Leather / canvas / plastic - over other material
  • from Radiomuseum.org
  • Model: De Luxe - Carad; Kuurne
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 295 x 230 x 85 mm / 11.6 x 9.1 x 3.3 inch
  • Notes

  • Carad, Portable Radio De Luxe, with French and German markings, destination probably the German speaking East of Belgium and/or export model for Germany.destination,

    with dial lamp, AFC, 3 presets for FM stations and sound regulation.

    See also model Universum K41.

  • Net weight (2.2 lb = 1 kg)
  • 2.5 kg / 5 lb 8.1 oz (5.507 lb)
  • Author
  • Model page created by Filip Sohier. See "Data change" for further contributors.
