• Country
• Germany

• Manufacturer / Brand
• CB-Master (Marke); Lütjensee

• Year
• 1990 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 282110

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 9

• Semiconductors

• Wave bands
• - without

• Power type and voltage
• Powered by external power supply or a main unit. / DC 9-13,8 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Auto Ranging Frequency Meter FQ-356 - CB-Master Marke; Lütjensee

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 107 x 35 x 125 mm / 4.2 x 1.4 x 4.9 inch

• Notes

• Auto Ranging Frequency Meter 0-350 MHz.
  Sensivity: 20 mV

• Net weight (2.2 lb = 1 kg)
• 0.4 kg / 0 lb 14.1 oz (0.881 lb)

• Author
• Model page created by a member from D. See "Data change" for further contributors.
