The Stratford 5C604 Ch= 1621
CBS-Columbia Inc.; New York, NY
- Country
- United States of America (USA)
- Manufacturer / Brand
- CBS-Columbia Inc.; New York, NY
- Year
- 1956 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 128213
-
- alternative name: CBS Electronics || Columbia Phonographs || Columbia Records
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 17
- Valves / Tubes
- 4BQ7A 5AT8 3CB6 3CB6 3CB6 12BY7A 3AU6 3BN6 12L6GT 7AU7 7AU7 12B4A 6SN7GT 12CU6 12AX4GT 1B3GT 24DP4A
- Main principle
- Superhet with RF-stage
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 60 cycles, 117V = 110 -120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: The Stratford 5C604 Ch= 1621 - CBS-Columbia Inc.; New York,
- Shape
- Console, Lowboy (legs < 50 %).
- Notes
-
CBS-Columbia model 5C604 is a 24" b/w TV with US standard VHF Cascode Turret tuner. Equipped with a Built-in antenna, chassis 1621 and picture tube 24DP4A . Turnabout base available. Mahogany finish.
- Source of data
- -- Original prospect or advert
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 321 Folder 3 dated 6-56)
- Author
- Model page created by a member from A. See "Data change" for further contributors.
