Generador de señales 532

• Country
• Spain

• Manufacturer / Brand
• Celbor, Laboratorios Electrónicos; Barcelona

• Year
• 1951 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 173532

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 3

• Valves / Tubes
• EBF80 EBF80 EZ81

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 125 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Generador de señales 532 - Celbor, Laboratorios

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 340 x 230 x 130 mm / 13.4 x 9.1 x 5.1 inch

• Notes

• Generador modulado a 400 Hz.
  Frecuencias de 100 kHz a 35 MHz en 5 bandas.
  Generador AF 5 V sobre 0,5 MΩ.

• Net weight (2.2 lb = 1 kg)
• 5.5 kg / 12 lb 1.8 oz (12.115 lb)

• Source of data
• - - Manufacturers Literature

• Mentioned in
• Anuncio de 1951

• Author
• Model page created by Rafael Chueca. See "Data change" for further contributors.
