- Country
- Italy
- Manufacturer / Brand
- CGE, Compagnia Generale di Elettricità; Milano
- Year
- 1968 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 192287
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 10
- Main principle
- Superheterodyne (common); ZF/IF 460/10700 kHz
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 110; 127; 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 2 W (unknown quality)
- from Radiomuseum.org
- Model: RT315 - CGE, Compagnia Generale di
- Shape
- Tablemodel with Push Buttons.
- Notes
- Gamme di ricezione:
OL: 150 ÷ 360 kHz.
OM: 520 ÷ 1620 kHz.
OC: 5,9 ÷ 6,25 MHz.
FM: 87,6 ÷ 104 MHz.
- Literature/Schematics (1)
- -- Schematic (Schemario di Apparecchi Radio a Transistori Vol. 8° Antonelliana)
- Literature/Schematics (2)
- -- Schematic (Schemario Radio Autoradio Mangianastri edizioni "Il Rostro" marzo 1971.)
- Author
- Model page created by Eduard Abfalterer. See "Data change" for further contributors.
