- Country
- Italy
- Manufacturer / Brand
- CGE, Compagnia Generale di Elettricità; Milano
- Year
- 1971 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 201035
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 9
- Main principle
- Superheterodyne (common); ZF/IF 460/10700 kHz
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Power out
- 1 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: RT390 - CGE, Compagnia Generale di
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 290 x 185 x 120 mm / 11.4 x 7.3 x 4.7 inch
- Notes
-
6 diodi.
Altoparlante ellittico 100 x 150 mm.
Antenna interna in ferrite per AM e prese per antenne esterne AM e MF.
- Mentioned in
- Catalogo ANIE (1970-71, p. 44)
- Literature/Schematics (1)
- -- Schematic (Schemario Radio Autoradio Mangianastri edizioni "Il Rostro" marzo 1971.)
- Author
- Model page created by Pasquale Baiocato. See "Data change" for further contributors.
