- Country
- Italy
- Manufacturer / Brand
- CGE, Compagnia Generale di Elettricità; Milano
- Year
- 1968
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 328272
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 18
- Valves / Tubes
- PC900 PCF801 EF183 EF183 EF184 PCL200 PCL84 PCF200 PCL84 EF184 PCC85 PCC85 PCL85 EF184 PL500 PY83 1AD2 11SP22
- Number of Transistors
- 4
- Main principle
- ZF/IF 38900/33400 kHz
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 cm = 3.1 inch
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: TPC279/11 - CGE, Compagnia Generale di
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 435 x 295 x 400 mm / 17.1 x 11.6 x 15.7 inch
- Notes
-
Televisore a colori con schermo da 11 pollici, portatile. Utilizza il sistema PAL semplice.
17 valvole, 4 transistor, 16 diodi ed un diodo raddrizzatore, tutti elencato una volta per tipo.
- Cinescopio 11" in line Shadow mask;
- 10 canali VHF + UHF;
- Due antenne esterne orientabili + due prese a 300 ohm.
- Price in first year of sale
- 299,000.00 ITL
- Source of data
- Catalogo ANIE
- Mentioned in
- -- Schematic (Il Video Libro, D.E. Ravalico, VII edizione, 1970; Hoepli)
- Literature/Schematics (1)
- Schemario TVC editr. "Il Rostro" vol. 5
- Author
- Model page created by Pier Antonio Aluffi. See "Data change" for further contributors.
