- Country
- Great Britain (UK)
- Manufacturer / Brand
- Champion Electric, Newhaven / Seaford
- Year
- 1954
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 127544
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Main principle
- TRF (Tuned-Radio-Frequency but use of regeneration unknown); 1 AF stage(s)
- Tuned circuits
- 2 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- AC/DC-set / 200-250 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Bakelite or Plastics (type unknown)
- from Radiomuseum.org
- Model: 784B - Champion Electric, Newhaven /
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Notes
- Same as model 784 except for valve line-up, & resistive mains cord replaced by a resistor.
- Source of data
- -- Schematic
- Literature/Schematics (1)
- Paul Stennings CD Vol 1
- Author
- Model page created by Keith Staines. See "Data change" for further contributors.
