Champion 750B
Champion Electric, Newhaven / Seaford
- Country
- Great Britain (UK)
- Manufacturer / Brand
- Champion Electric, Newhaven / Seaford
- Year
- 1951
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 79352
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 465 kHz
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- AC/DC-set / 100-120; 200-250 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Bakelite case
- from Radiomuseum.org
- Model: Champion 750B - Champion Electric, Newhaven /
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 12.5 x 7.5 x 6.5 inch / 318 x 191 x 165 mm
- Notes
- Wave bands for Model 750B: Shortwave 16-49 m, Medium wave 200-550 m and Long wave 800-2000 m. See also export model 750A with medium and two shortwave bands.
- Source of data
- Radio! Radio!
- Literature/Schematics (1)
- -- Original-techn. papers.
- Literature/Schematics (2)
- Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (1050)
- Author
- Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
