• Country
• Great Britain (UK)

• Manufacturer / Brand
• Champion Electric, Newhaven / Seaford

• Year
• 1958 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 103261

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• ECC85 ECH81 EF89 EABC80 EL84 EZ80

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and FM or UHF.

• Details
• Record Player (perh.Changer)

• Power type and voltage
• Alternating Current supply (AC) / 200-250 Volt

• Loudspeaker
• 3 Loudspeakers

• from Radiomuseum.org
• Model: Sonata 841 - Champion Electric, Newhaven /

• Shape
• Tablemodel, with any shape - general.

• Mentioned in
• -- Original-techn. papers.

• Author
• Model page created by Peter Hoddow. See "Data change" for further contributors.

• Other Models

• Here you find 57 models, 37 with images and 49 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
