• Country
• Spain

• Manufacturer / Brand
• Clarión; Barcelona

• Year
• 1953 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 127465

• Number of Tubes
• 5

• Valves / Tubes
• ECH42 EAF42 EBC42 EL41 EZ90

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• Alternating Current supply (AC) / 125V Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 16 cm = 6.3 inch

• Power out
• 3 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Clari V48 - Clarión; Barcelona

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 480 x 380 x 250 mm / 18.9 x 15 x 9.8 inch

• Net weight (2.2 lb = 1 kg)
• 7 kg / 15 lb 6.7 oz (15.419 lb)

• Author
• Model page created by Diego Fernandez-Fernandez. See "Data change" for further contributors.
