• Country
• Spain

• Manufacturer / Brand
• Clarión; Barcelona

• Year
• 1941/1942

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 318922

• Number of Tubes
• 5

• Valves / Tubes

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• AC/DC-set / 110 Volt

• Loudspeaker
• Permanent or electro-dynamic (moving coil), system not known yet. / Ø 6 inch = 15.2 cm

• Material
• Wooden case

• from Radiomuseum.org
• Model: RA-41-U - Clarión; Barcelona

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 330 x 230 x 210 mm / 13 x 9.1 x 8.3 inch

• Notes

• Clarión (Barcelona) RA-41-U

  Véase mismo modelo en corriente alterna RA-41-A

• Price in first year of sale
• 2,075.00 Pts

• Mentioned in
• Catálogo Clarión 1942 (septiembre 1941)

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.

• Other Models

• Here you find 92 models, 85 with images and 2 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Clarión; Barcelona
