• Country
• Spain

• Manufacturer / Brand
• Clarivox, S.A., Electrónica; Zaragoza

• Year
• 1981

• Category
• Radio module post 1925 (not a part, not a key)

• Radiomuseum.org ID
• 311246

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 8

• Semiconductors
• BC158 BD135 BC547 BC557 BC557 BC557 BC557 BC557 CD4011 SAB3022 or. SAB3023 SN29770 SN29771 CD4013 LM1017 5082-7760 1N4148 ZTK33

• Main principle
• PLL, Phase-locked loop

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Powered by external power supply or a main unit. / 12 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Módulo de Sintonía para TV Máster MC2-X - Clarivox, S.A., Electrónica;

• Shape
• Miscellaneous shapes - described under notes.

• Notes

• El Máster MC2-X de Clarivox es un módulo con 8 presintonías, preparado para la incorporación del conjunto de telemando por infrarrojos tipo TLX.

  Utiliza un integrado N-Mos tipo SAB3022B (ó SAB3023B), pudiendo manejar 18 funciones de control en forma local y 22 funciones cuando se incorpora el mando a distancia.

  Puede utilizarse en los televisores Clarivox Z96S, Z96X y Z96XM.

• Mentioned in
• -- Original-techn. papers. (Clarivox boletín 5-83 y 6-83)

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
