• Country
• Great Britain (UK)

• Manufacturer / Brand
• Atlas (Brand) H. Clarke & Co. (Manchester) Ltd.; Manchester

• Year
• 1934

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 78169

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• FC4 VP4 TDD4 AC044 IW3

• Main principle
• Superheterodyne (common); ZF/IF 117.5 kHz

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Alternating Current supply (AC) / 200-250 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Atlas 758 - Atlas Brand H. Clarke & Co.

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 22.25 x 11 x 11.5 inch / 565 x 279 x 292 mm

• Notes
• Diagonally positioned loudspeaker. Hinged tuning scale.

• Source of data
• Radio! Radio!

• Literature/Schematics (1)
• Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (25)

• Author
• Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.

• Other Models

• Here you find 19 models, 14 with images and 2 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Atlas (Brand) H. Clarke & Co. (Manchester) Ltd.; Manchester
