- Country
- United States of America (USA)
- Manufacturer / Brand
- Clinton Mfg.Co.; Chicago, IL
- Year
- 1938 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 231900
- Number of Tubes
- 4
- Main principle
- TRF without regeneration
- Tuned circuits
- 2 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- AC/DC-set / 105-120 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 3 inch = 7.6 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: 440 - Clinton Mfg.Co.; Chicago, IL
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 6.75 x 4.75 x 4.5 inch / 171 x 121 x 114 mm
- Notes
-
See Firestone S7425 for schematic. 1938 Clinton manufacturing operation was sold to Sonora Radio & Television Corp. of Chicago.
- Author
- Model page created by John Backscheider. See "Data change" for further contributors.
- Other Models
-
Here you find 135 models, 81 with images and 47 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Clinton Mfg.Co.; Chicago, IL
Collections
The model 440 is part of the collections of the following members.
