• Country
• United States of America (USA)

• Manufacturer / Brand
• Clinton Mfg.Co.; Chicago, IL

• Year
• 1938 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 336704

• Number of Tubes
• 6

• Valves / Tubes
• 6A7 6D6 75 43 25Z5 6U5 165R8

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Short Wave(s) and Police.

• Power type and voltage
• Alternating Current supply (AC) / 110/220 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Power out
• 2 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Cybele - Clinton Mfg.Co.; Chicago, IL

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 410 x 250 x 185 mm / 16.1 x 9.8 x 7.3 inch

• Notes

• Manudacturer is not known with certainty.

• Net weight (2.2 lb = 1 kg)
• 5 kg / 11 lb 0.2 oz (11.013 lb)

• Author
• Model page created by Francisco Martins. See "Data change" for further contributors.

• Other Models

• Here you find 135 models, 81 with images and 47 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
