3 Valve Battery Receiver B210
Co-operative Wholesale Society (CWS) - Defiant; Manchester
- Country
- Great Britain (UK)
- Manufacturer / Brand
- Co-operative Wholesale Society (CWS) - Defiant; Manchester
- Year
- 1934 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 334779
-
- Brand: Defiant
- Number of Tubes
- 3
- Main principle
- TRF with regeneration
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Storage and/or dry batteries
- Loudspeaker
- Magnetic loudspeaker (reed) generic. / Ø 8 inch = 20.3 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: 3 Valve Battery Receiver B210 - Co-operative Wholesale Society
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Dimensions (WHD)
- 495 x 345 x 235 mm / 19.5 x 13.6 x 9.3 inch
- Notes
-
A 2 band battery table radio housed in a wooden case. With sockets for aerial, earth, gramophone pickup and extension loudspeaker.
- Author
- Model page created by David Humphrey. See "Data change" for further contributors.
