- Country
- United States of America (USA)
- Manufacturer / Brand
- B&K (Precision), Dynascan Corp., Cobra Electronics; Chicago, IL and Yorba Linda, CA
- Year
- 1998 ?
- Category
- Citizen Band Equipment
- Radiomuseum.org ID
- 279925
-
- alternative name: B&K Manufacturing Company
Bedienanleitung
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Transceiver; ZF/IF 10700/455 kHz
- Wave bands
- Short Wave (SW only)
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 13,8 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Metal case
- from Radiomuseum.org
- Model: Cobra INTL75ST - B&K Precision, Dynascan Corp.,
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 48 x 108 x 70 mm / 1.9 x 4.3 x 2.8 inch
- Notes
-
CB-Funk Mobilgerät mit abgesetztem Bedienteil, 40 Kanäle FM, Doppel-Superhet.
26,965 bis27,405 MHz
- Net weight (2.2 lb = 1 kg)
- 0.453 kg / 0 lb 16 oz (0.998 lb)
- Literature/Schematics (1)
- Vom Hersteller
- Author
- Model page created by Egon Strampe. See "Data change" for further contributors.
