Sherwood 166M
Columbus (Brand); Radio Centre Ltd.; Wellington
- Country
- New Zealand-Aotearoa
- Manufacturer / Brand
- Columbus (Brand); Radio Centre Ltd.; Wellington
- Year
- 1953 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 338434
- Number of Tubes
- 6
- Main principle
- Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Alternating Current supply (AC) / 230 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 8 inch = 20.3 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: Sherwood 166M - Columbus Brand; Radio Centre
- Shape
- Tablemodel, low profile (big size).
- Notes
-
6-Valve superhet with RF stage dual wave receiver with new valve line up.
See also table Model 166 Sherwood, table Model 166R Sherwood, table Model 166 Edinburgh, table radiogram Model 166 Peannnt, console Model 166 Balfour & console Model 166 Convoy.
Manufactured by Radio Corporation Of New Zealand Ltd for Columbus Radio Centre Ltd.
- Mentioned in
- More Golden Age of Radio (Page 118)
- Literature/Schematics (1)
- -- Original prospect or advert (Press 17 September 1953 Page 14)
- Author
- Model page created by Brian Stevens. See "Data change" for further contributors.
