• Country
• Spain

• Manufacturer / Brand
• Comercial Radio Bertrán; Electrónica Bertrán; ELBE; Barcelona

• Year
• 1950

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 249484

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 12BE6 12BA6 12AT6 50B5 35W4

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• AC/DC-set / 125 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3 inch = 7.6 cm

• Material
• Bakelite case

• from Radiomuseum.org
• Model: Mini - Comercial Radio Bertrán;

• Notes

• Receptor típico de los años cincuenta,con caja de bakelita, de poco peso y apto para instalar en una mesita de noche.
