Receiver 500

Conar Instruments; Washington (DC)

Data

Forum

Pictures

Collections

Country
United States of America (USA)

Manufacturer / Brand
Conar Instruments; Washington (DC)

Year
1965 ?

Category
Amateur-Receiver (amateur bands, may include broadcast bands)

Radiomuseum.org ID
285251

Schematics

Receiver 500; Conar Instruments; (ID = 2041038) Amateur-R — Conar Instruments; Receiver 500 (3)

Receiver 500; Conar Instruments; (ID = 2732250) Amateur-R — Conar Instruments; Receiver 500 (3)

Receiver 500; Conar Instruments; (ID = 2732251) Amateur-R — Conar Instruments; Receiver 500 (3)

Receiver 500; Conar Instruments; (ID = 2732252) Amateur-R — Conar Instruments; Receiver 500 (3)

Receiver 500; Conar Instruments; (ID = 2732253) Amateur-R — Conar Instruments; Receiver 500 (3)

Receiver 500; Conar Instruments; (ID = 2732254) Amateur-R — Conar Instruments; Receiver 500 (3)

Receiver 500; Conar Instruments; (ID = 2732256) Amateur-R — Conar Instruments; Receiver 500 (3)

Receiver 500; Conar Instruments; (ID = 2732258) Amateur-R — Conar Instruments; Receiver 500 (3)

Receiver 500; Conar Instruments; (ID = 2040726) Amateur-R — Conar Instruments; Receiver 500 (2)

Receiver 500; Conar Instruments; (ID = 2041535) Amateur-R — Conar Instruments; Receiver 500 (2)

Receiver 500; Conar Instruments; (ID = 2041536) Amateur-R — Conar Instruments; Receiver 500 (2)

Receiver 500; Conar Instruments; (ID = 2041537) Amateur-R — Conar Instruments; Receiver 500 (2)

Receiver 500; Conar Instruments; (ID = 2041538) Amateur-R — Conar Instruments; Receiver 500 (2)

Receiver 500; Conar Instruments; (ID = 2656477) Amateur-R — Conar Instruments; Receiver 500 (1)
Conar 500 three-band ham receiver

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Tubes
4

Valves / Tubes
6BE6 6BZ6 6U8 6U8

Main principle
Superheterodyne (common)

Wave bands
Short Wave (SW only)

Power type and voltage
Alternating Current supply (AC) / 60Hz, 115 Volt

Loudspeaker
Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

Material
Metal case

from Radiomuseum.org
Model: Receiver 500 - Conar Instruments; Washington

Shape
Tablemodel without push buttons, Mantel/Midget/Compact up to 14

Dimensions (WHD)
10 x 7.5 x 6.5 inch / 254 x 191 x 165 mm

Notes
3 bands: 80, 40, 15 meter; AM and CW.

Price is for kit offered by NRI (National Radio Institute). Assembled price is $56.50.

Price in first year of sale
37.50 USD

Mentioned in
Advertisement in 1965 ARRL Handbook

Author
Model page created by Gottfried Silberhorn. See "Data change" for further contributors.

Other Models
Here you find 18 models, 17 with images and 8 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Conar Instruments; Washington (DC)

Collections | Museums | Literature

Collections

The model Receiver is part of the collections of the following members.

Rich Post (USA)
