• Year
  • 1962 ?
  • Category
  • Car Radio, perhaps also + sound player/recorder
  • Radiomuseum.org ID
  • 177851

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 7
  • Main principle
  • Superheterodyne (common); ZF/IF 250 kHz
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Storage Battery for all (e.g. for car radios and amateur radios) / 6 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 6 W (unknown quality)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: GK2610 Tipo B - Condor Ing. Gallo; Milano
  • Shape
  • Chassis only or for «building in»
  • Notes
  • Gamma di frequenza.
    OM: 520 ÷ 1620 kHz.
    5 tasti per comando sintonia automatica.
    Presa per comando antenna elettrica automatica.
  • Literature/Schematics (1)
  • Schemario di Apparecchi a Transistori Vol. 3° R. Rosati
  • Author
  • Model page created by Eduard Abfalterer. See "Data change" for further contributors.
