• Country
• United States of America (USA)

• Manufacturer / Brand
• Conrac Inc.; Baldwin Park (CA)

• Year
• 1956

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 100593

• • Brand: Peyton

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 25

• Valves / Tubes
• 6BQ7A 6J6 6CB6 6AU6 6AU6 6AU6 6AL5 12BY7 6AU6 6AN8 6AU6 6AU6 6AL5 6AV6 6V6GT 6BY6 6SN7GTB 6W6GT 6AL5 6SN7GTB 6CD6G 6AU4GT 1B3GT 5U4GB 24CP4A

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 60 cycles, 117V = 110 -120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Metal case

• from Radiomuseum.org
• Model: Fleetwood 810 - Conrac Inc.; Baldwin Park CA

• Shape
• Chassis only or for «building in»

• Notes

• For 21, 24 and 27" picture tubes, 90º deflection.

  Fleetwood model 810 is a 21" b/w TV with US standard VHF Tuner channels 2 thru 13 ,Equipped with picture tube 24cP4A.



• Price in first year of sale
• 230.00 $

• Literature/Schematics (1)
• Allied Radio Catalog Nº 150, 1956

• Literature/Schematics (2)
• Photofact Folder, Howard W. SAMS (Set 314 Folder 4)

• Author
• Model page created by Vitor Oliveira. See "Data change" for further contributors.
