LCR Messgerät LCR-100
Conrad Electronic (Voltcraft), Radio-Conrad, Conrad & Co; Berlin, Hirschau
- Country
- Germany
- Manufacturer / Brand
- Conrad Electronic (Voltcraft), Radio-Conrad, Conrad & Co; Berlin, Hirschau
- Year
- 2010 ??
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 347273
-
- Brand: Voltcraft
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Wave bands
- - without
- Power type and voltage
- Dry Batteries / AA: 2 x 1,5 Volt
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: LCR Messgerät LCR-100 - Conrad Electronic Voltcraft,
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 82 x 183 x 55 mm / 3.2 x 7.2 x 2.2 inch
- Notes
-
Messbereiche (Grundgenauigkeit 0,5%):
- Induktivität 1 µH - 20 H
- Kapazität 1 pF - 110 mF
- Widerstand 0,01 Ω - 110 MΩ
- Messfrequenz 100/1000 Hz
- Diodentest
- Durchgangsprüfer
- Author
- Model page created by Gil Silva. See "Data change" for further contributors.
