9-207M

Crosley Radio Corp.; Cincinnati (OH)

Data

Forum

Pictures

Collections

Country
United States of America (USA)

Manufacturer / Brand
Crosley Radio Corp.; Cincinnati (OH)

Year
1952 ??

Category
Broadcast Receiver - or past WW2 Tuner

Radiomuseum.org ID
36046

Schematics

9-207M ; Crosley Radio Corp.; (ID = 263565) Radio — Crosley Radio Corp.; 9-207M (3)

9-207M ; Crosley Radio Corp.; (ID = 263566) Radio — Crosley Radio Corp.; 9-207M (3)

9-207M ; Crosley Radio Corp.; (ID = 263567) Radio — Crosley Radio Corp.; 9-207M (3)

9-207M ; Crosley Radio Corp.; (ID = 263568) Radio — Crosley Radio Corp.; 9-207M (3)

9-207M ; Crosley Radio Corp.; (ID = 263569) Radio — Crosley Radio Corp.; 9-207M (3)

9-207M ; Crosley Radio Corp.; (ID = 263570) Radio — Crosley Radio Corp.; 9-207M (3)

9-207M ; Crosley Radio Corp.; (ID = 263571) Radio — Crosley Radio Corp.; 9-207M (3)

9-207M ; Crosley Radio Corp.; (ID = 263572) Radio — Crosley Radio Corp.; 9-207M (3)

9-207M ; Crosley Radio Corp.; (ID = 1509471) Radio — Crosley Radio Corp.; 9-207M (3)

9-207M ; Crosley Radio Corp.; (ID = 1509472) Radio — Crosley Radio Corp.; 9-207M (3)

9-207M ; Crosley Radio Corp.; (ID = 1509473) Radio — Crosley Radio Corp.; 9-207M (3)

9-207M ; Crosley Radio Corp.; (ID = 1509474) Radio — Crosley Radio Corp.; 9-207M (3)

9-207M ; Crosley Radio Corp.; (ID = 1509475) Radio — Crosley Radio Corp.; 9-207M (3)

9-207M ; Crosley Radio Corp.; (ID = 1509476) Radio — Crosley Radio Corp.; 9-207M (3)

9-207M ; Crosley Radio Corp.; (ID = 1509477) Radio — Crosley Radio Corp.; 9-207M (3)

9-207M ; Crosley Radio Corp.; (ID = 1509478) Radio — Crosley Radio Corp.; 9-207M (3)

9-207M ; Crosley Radio Corp.; (ID = 1509479) Radio — Crosley Radio Corp.; 9-207M (3)

9-207M ; Crosley Radio Corp.; (ID = 1509480) Radio — Crosley Radio Corp.; 9-207M (3)

9-207M ; Crosley Radio Corp.; (ID = 263564) Radio — Crosley Radio Corp.; 9-207M (2)

9-207M ; Crosley Radio Corp.; (ID = 1509470) Radio — Crosley Radio Corp.; 9-207M (2)

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Tubes
11

Valves / Tubes
6SG7 7F8 6AC7 6SG7 6SG7 6AL5 6SQ7 6SQ7 6V6GT 6V6GT 5Y3GT

Main principle
Superheterodyne (common); ZF/IF 455/10700 kHz

Wave bands
Broadcast, Short Wave plus FM or UHF.

Details
Changer (Record changer)

Power type and voltage
Alternating Current supply (AC) / 110 - 120 Volt

Loudspeaker
Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

Power out
10 W (unknown quality)

Material
Wooden case

from Radiomuseum.org
Model: 9-207M - Crosley Radio Corp.;

Shape
Console, Lowboy (legs < 50 %).

External source of data
Ernst Erb

Circuit diagram reference
Rider's Perpetual, Volume 20 covering 1950
