Anglotutor K-8530 (CK-8530)
Cosmo S.A., Industrias; Granollers (Barcelona)
- Country
- Spain
- Manufacturer / Brand
- Cosmo S.A., Industrias; Granollers (Barcelona)
- Year
- 1976
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 315542
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 17
- Semiconductors
- BC149 BC149 BC149 BC149 BC149 BC149 SC149 BC149 BC149 BC149 BC149 BC149 BD135 AC187 BD131 TCA910 AA119
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Cassette-Recorder or -Player
- Power type and voltage
- Alternating Current supply (AC) / 125; 220 Volt
- Loudspeaker
- - only for Earphone!
- Power out
- 12 W (undistorted)
- from Radiomuseum.org
- Model: Anglotutor K-8530 - Cosmo S.A., Industrias;
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 370 x 85 x 280 mm / 14.6 x 3.3 x 11 inch
- Notes
-
Industrias Cosmo, S.A. Anglotutor Cassette para estudio de idiomas K-8530 (CK-8530)
Posibilidad de uso simultáneo de pista de profesor en reproducción y pista de alumno en grabación o reproducción.
- Net weight (2.2 lb = 1 kg)
- 3 kg / 6 lb 9.7 oz (6.608 lb)
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
