• Country
• Great Britain (UK)

• Manufacturer / Brand
• Cossor, A.C.; London

• Year
• 1946

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 79035

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• OM10 OM6 OM4 6V6G 6X5G

• Main principle
• Superheterodyne (common); ZF/IF 465 kHz

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 200-255 Volt

• Loudspeaker
• Permanent or electro-dynamic (moving coil), system not known yet.

• Material
• Bakelite case

• from Radiomuseum.org
• Model: 464 [ivory] - Cossor, A.C.; London

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 13.5 x 9 x 6.75 inch / 343 x 229 x 171 mm

• Notes
• available in black, and (sprayed) green or ivory

• Price in first year of sale
• 18.00 GBP

• Source of data
• Radio! Radio!

• Literature/Schematics (1)
• - - Manufacturers Literature

• Literature/Schematics (2)
• Trader sheet 775

• Author
• Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.

• Other Models

• Here you find 326 models, 250 with images and 194 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
