Dublette mit ID=103384
Cossor, A.C.; London
- Country
- Great Britain (UK)
- Manufacturer / Brand
- Cossor, A.C.; London
- Year
- 9999/9999
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 140932
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 465 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 200-255 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- from Radiomuseum.org
- Model: Dublette mit ID=103384 - Cossor, A.C.; London
- Shape
- Console with any shape - in general
- Notes
- Same chassis as model 470AC.
- Source of data
- -- Schematic
- Literature/Schematics (1)
- R&TVS. Vol I, Page 121. Trader Sheet 835.
- Author
- Model page created by Keith Staines. See "Data change" for further contributors.
