Battery Melody Maker 238
Cossor, A.C.; London
- Country
- Great Britain (UK)
- Manufacturer / Brand
- Cossor, A.C.; London
- Year
- 1937 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 333068
- Number of Tubes
- 3
- Valves / Tubes
- 210VPT 210SPT 220HPT_5pin
- Main principle
- TRF with regeneration
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Storage and/or dry batteries / 120 + 45 + 9 + 4.5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: Battery Melody Maker 238 - Cossor, A.C.; London
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Dimensions (WHD)
- 14 x 19 x 10 inch / 356 x 483 x 254 mm
- Notes
-
A 2 band battery valve table radio housed in a walnut wooden cabinet. Connections for aerial, earth, gramophone pickup and extension loudspeaker.
- Mentioned in
- - - Manufacturers Literature (Cossor Service Hints and Instructions)
- Author
- Model page created by Howard Craven. See "Data change" for further contributors.
