Melody Maker 501AC Rimlock valves

Cossor, A.C.; London

Data

Forum

Pictures

Collections

Country
Great Britain (UK)

Manufacturer / Brand
Cossor, A.C.; London

Year
1950

Category
Broadcast Receiver - or past WW2 Tuner

Radiomuseum.org ID
119213

Schematics

Melody Maker 501AC; Cossor, A.C.; London (ID = 530115) Radio — Cossor, A.C.; London Melody Maker 501AC (3)

Melody Maker 501AC; Cossor, A.C.; London (ID = 530116) Radio — Cossor, A.C.; London Melody Maker 501AC (3)

Melody Maker 501AC; Cossor, A.C.; London (ID = 1001144) Radio — Cossor, A.C.; London Melody Maker 501AC (3)

Melody Maker 501AC; Cossor, A.C.; London (ID = 1001145) Radio — Cossor, A.C.; London Melody Maker 501AC (3)

Melody Maker 501AC; Cossor, A.C.; London (ID = 3107535) Radio — Cossor, A.C.; London Melody Maker 501AC (1)

Melody Maker 501AC; Cossor, A.C.; London (ID = 3107537) Radio — Cossor, A.C.; London Melody Maker 501AC (1)

Melody Maker 501AC; Cossor, A.C.; London (ID = 3107536) Radio — Cossor, A.C.; London Melody Maker 501AC (1)

Melody Maker 501AC; Cossor, A.C.; London (ID = 3107540) Radio — Cossor, A.C.; London Melody Maker 501AC (1)

Melody Maker 501AC; Cossor, A.C.; London (ID = 3107538) Radio — Cossor, A.C.; London Melody Maker 501AC (1)

Melody Maker 501AC; Cossor, A.C.; London (ID = 3107539) Radio — Cossor, A.C.; London Melody Maker 501AC (1)

Melody Maker 501AC; Cossor, A.C.; London (ID = 364795) Radio — Cossor, A.C.; London Melody Maker 501AC (1)

Melody Maker 501AC; Cossor, A.C.; London (ID = 364796) Radio — Cossor, A.C.; London Melody Maker 501AC (1)

Melody Maker 501AC; Cossor, A.C.; London (ID = 364797) Radio — Cossor, A.C.; London Melody Maker 501AC (1)

Melody Maker 501AC; Cossor, A.C.; London (ID = 364798) Radio — Cossor, A.C.; London Melody Maker 501AC (1)

Melody Maker 501AC; Cossor, A.C.; London (ID = 364806) Radio — Cossor, A.C.; London Melody Maker 501AC (1)

Melody Maker 501AC; Cossor, A.C.; London (ID = 364810) Radio — Cossor, A.C.; London Melody Maker 501AC (1)

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Tubes
5

Valves / Tubes
62TH or ECH42 62VP or EF41 62DDT or EBC41 67PT or EL41 66KU or EZ40

Main principle
Superheterodyne (common); ZF/IF 470 kHz; 2 AF stage(s)

Tuned circuits
6 AM circuit(s)

Wave bands
Broadcast, Long Wave and Short Wave.

Power type and voltage
Alternating Current supply (AC) / 200-255 Volt

Loudspeaker
Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 20 cm = 7.9 inch

Material
Bakelite case

from Radiomuseum.org
Model: Melody Maker 501AC [Rimlock valves] - Cossor, A.C.; London

Shape
Tablemodel, low profile (big size).

Dimensions (WHD)
447 x 275 x 200 mm / 17.6 x 10.8 x 7.9 inch

Notes
There is also a variant using loctal valves. Dial lamp 6,5V 0,3A

Source of data
- - Data from my own collection

Author
Model page created by Antonio Martins-Pais. See "Data change" for further contributors.
