• Country
• New Zealand-Aotearoa

• Manufacturer / Brand
• Courtenay (Brand); Various manufacturers

• Year
• 1940

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 356028

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• X65 KTW61 DH63 KT61 U50

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• Alternating Current supply (AC) / 50Hz, 230 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 10 inch = 25.4 cm

• Material
• Wooden case

• from Radiomuseum.org
• Model: 052 [Console] - Courtenay Brand; Various

• Shape
• Console with any shape - in general

• Notes

• Courtenay 052 Console

  5-Valve superhet broadcast (MW) table model receiver.

  See also Broadcast only mantel version Courtenay 051 and dual wave mantel Courtenay Model 52S with similar but different chassis.

  Manufactured by Radio Corporation Of New Zealand Ltd for Turnbull & Jones Ltd.

• Author
• Model page created by Brian Stevens. See "Data change" for further contributors.
