- Country
- New Zealand-Aotearoa
- Manufacturer / Brand
- Courtenay (Brand); Various manufacturers
- Year
- 1937
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 340377
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 13
- Main principle
- Superhet with RF-stage; ZF/IF 456 kHz; 5 AF stage(s)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast plus 2 Short Wave bands.
- Power type and voltage
- Alternating Current supply (AC) / 230 Volt
- Loudspeaker
- 2 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: 47 - Courtenay Brand; Various
- Shape
- Console with any shape - in general
- Notes
-
13-Valve superhet with RF stage all wave receiver comprising of Courtenay Model 43 9-valve receiver and a 4-valve power amplifier on a separate chassis.
Designed to meet the demand for a "super" high-fidelity set.
There are two audio channels, one each for high and low frequencies. The 6F6 drives a 6 inch electrodynamic tweeter and the 6L6s drive a 12 inch permanent magnet woofer.
Each chassis has it's own power supply.
See also Columbus Model 47.
Manufactured for Turnbull & Jones Ltd by Radio Corporation of NZ Ltd.
