- Country
- United States of America (USA)
- Manufacturer / Brand
- Crescent Industries, Inc.; Chicago, IL
- Year
- 1948 ?
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 133691
SAMS Photofact reference picture.
Click on the schematic thumbnail to request the schematic as a free document.
- Wave bands
- - without
- Details
- Wire Recorder (or -Player)
- Power type and voltage
- Alternating Current supply (AC) / 105-125 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: CRW-30 - Crescent Industries, Inc.;
- Shape
- Chassis only or for «building in»
- Notes
- The Crescent 1000 Series Wire Recorder made by Crescent Industries, Inc., Chicago, is a combination record player and magnetic recorder-reproducer. The standard spool gives approximately an hour of continuous recording. There are different chassis like C-1000 Series, M-1000 Series and E-1000 Series. The CWR30 and E-1000 series use the WR21-B Pickup arm and pivot spring assemly and the C-1000 and M-1000 series use the WR50 pickup arm and pivot spring assembly. The motor can be for 105-125 volts, 60 cycles (standard) or ordered for 220 volts 60 cycles. Both tensions can be ordered for 50 cycles.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Date 11-49, set 77, folder 4)
- Author
- Model page created by Ernst Erb. See "Data change" for further contributors.
