• Country
• United States of America (USA)

• Manufacturer / Brand
• Crosley Radio Corp.; Cincinnati (OH)

• Year
• 1939/1940

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 36866

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• 6A8 6K7 6Q7 6P5 6AC5 5Y3

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz; 3 AF stage(s)

• Wave bands
• Broadcast only (MW).

• Details
• Record Player (perh.Changer)

• Power type and voltage
• Alternating Current supply (AC) / 117 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 8 inch = 20.3 cm

• Power out
• 5 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 629M Ch= 629 [6A8 2nd Series] - Crosley Radio Corp.;

• Shape
• Console with Push Buttons.

• Dimensions (WHD)
• 33.25 x 33.625 x 14 inch / 845 x 854 x 356 mm

• Notes

• Not to be confused with the early mini tombstone 629 of 1936. Please look up common information here for this season.

• Price in first year of sale
• 69.95 $

• External source of data
• Ernst Erb

• Circuit diagram reference
• Rider's Perpetual, Volume 14 = 1944 = before 1943

• Literature/Schematics (3)
• Crosley Folder No. 2451B, Season 1939/40.
