• Country
• United States of America (USA)

• Manufacturer / Brand
• Crosley Radio Corp.; Cincinnati (OH)

• Year
• 1927–1929

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 36430

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• UX226 UX226 UX226 UY227 UX226 UX171

• Main principle
• TRF without regeneration; 2 AF stage(s); Neutrodyne

• Tuned circuits
• 3 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Alternating Current supply (AC) / 110 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Metal case

• from Radiomuseum.org
• Model: Bandbox 602 - Crosley Radio Corp.;

• Shape
• Tablemodel, Box - most often with Lid (NOT slant panel).

• Notes
• There is a Bandbox 601 for battery operation and a Bandbox 602 intended to run on a separate unit (with a rectifier) on 110 volts AC. The device generates the different voltages AC and DC. Crosley calls it "Power Converter" and it supplies the required A, B and C currents. there are models for 25 or 60 cycles current, bov for $ 60. One dial (primary tuning control knob).

• Price in first year of sale
• 60.00 $

• External source of data
• Ernst Erb

• Source of data
• Radio Collector`s Guide 1921-1932

• Circuit diagram reference
• Rider's Perpetual, Volume 1 = 1931/1934 (for 1919-1931)

• Mentioned in
• Popular Mechanics (Ad September 1927 on page 168.)

• Other Models

• Here you find 1784 models, 1047 with images and 1274 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
