BC-12MZ Ch= 489
Crosley Radio Corp.; Cincinnati (OH)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Crosley Radio Corp.; Cincinnati (OH)
- Year
- 1957 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 271849
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 17
- Valves / Tubes
- 4BQ7A 5BR8 3BZ6 3BZ6 3CB6 12BY7A 5CM8 3BN6 12BK5 3CS6 6CS7 6CN7 6CG7 12DQ6 12AX4GT 1X2B 21ATP4 or 21ATP4A
- Main principle
- Superhet with RF-stage
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 110-120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 inch = 25.4 cm
- from Radiomuseum.org
- Model: BC-12MZ Ch= 489 - Crosley Radio Corp.;
- Shape
- Console with any shape - in general
- Notes
-
The Crosley BC-12MZ is a 21" b/w TV with US standard VHF Tuner channels 2 thru 13. Equipped with chassis 489 and picture tube 21ATP4 or 21ATP4A.
- Mentioned in
- Photofact Folder, Howard W. SAMS (Set 352, Folder 5, Date 3-57)
- Author
- Model page created by Arpad Roth † 27.3.17. See "Data change" for further contributors.
