6-Transistor TR-333
Crown Radio Corp.; Tokyo
- Country
- Japan
- Manufacturer / Brand
- Crown Radio Corp.; Tokyo
- Year
- 1963 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 103530
-
- alternative name: Asahi Radio Mfg. Co., Ltd
Ebay AUS user ach01 220888079488
Ebay AUS user ach01 220888079488
Ebay AUS user ach01 220888079488
Ebay AUS user ach01 220888079488
- Number of Transistors
- 6
- Semiconductors
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 5 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Dry Batteries / 1 x 9 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: 6-Transistor TR-333 - Crown Radio Corp.; Tokyo
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 2.5 x 3.83 x 1.25 inch / 64 x 97 x 32 mm
- Notes
-
Crown TR-333 6-Transistor Radio;
See also the 3-transistor models Crown TR-333 early and Crown TR-333 late, both with reflex circuitry.
- Author
- Model page created by a member from A. See "Data change" for further contributors.
- Other Models
-
Here you find 369 models, 337 with images and 98 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Crown Radio Corp.; Tokyo
