Super All Transistor TR-830
Crown Radio Corp.; Tokyo
- Country
- Japan
- Manufacturer / Brand
- Crown Radio Corp.; Tokyo
- Year
- 1959 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 139026
-
- alternative name: Asahi Radio Mfg. Co., Ltd
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 4
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Tuned circuits
- 4 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Dry Batteries / 9 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 2.5 inch = 6.4 cm
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Super All Transistor TR-830 - Crown Radio Corp.; Tokyo
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Notes
- Empfangsfrequenzbereich: 525-1650 kHz
Stromaufnahme: ca. 7 mA bei 9 V
Diode: SD-46 (1N60)
USA-Importeur: Shriro, Inc., 276 Fourth Ave., New York 10, N.Y.
- Circuit diagram reference
- Photofact Folder, Howard W. SAMS
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 462, Folder 6, Date 11-59)
- Author
- Model page created by Knut Rothstein. See "Data change" for further contributors.
