10-Transistor Transceiver TRQ-1050 (Japan 105)
Crown Radio Corp.; Tokyo
- Country
- Japan
- Manufacturer / Brand
- Crown Radio Corp.; Tokyo
- Year
- 1962–1964
- Category
- Citizen Band Equipment
- Radiomuseum.org ID
- 189827
-
- alternative name: Asahi Radio Mfg. Co., Ltd
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 10
- Semiconductors
- Main principle
- Transceiver; ZF/IF 455 kHz
- Wave bands
- Short Wave (SW only)
- Power type and voltage
- Dry Batteries / 6 x 1,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 2.25 inch = 5.7 cm
- Material
- Metal case
- from Radiomuseum.org
- Model: 10-Transistor Transceiver TRQ-1050 - Crown Radio Corp.; Tokyo
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 72 x 178 x 38 mm / 2.8 x 7 x 1.5 inch
- Notes
-
Handfunkgerät, ein Kanal im 27 MHz-CB-Band, Steckquarze.
Buchse für Ohrhörer.Made in Japan 105
- Net weight (2.2 lb = 1 kg)
- 0.3 kg / 0 lb 10.6 oz (0.661 lb)
- Author
- Model page created by Eckhard Wegner. See "Data change" for further contributors.
