MD1612 Ch= 12B
Curtis Mathes MfG. Co.; Dallas (TX)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Curtis Mathes MfG. Co.; Dallas (TX)
- Year
- 1959 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 147179
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 17
- Valves / Tubes
- 6BQ7A 6BA6 6AU6 6AL5 6E5 6BA6 6BE6 6BA6 6AV6 7025 7025 12AX7 EL84 EL84 EL84 EL84 5U4GB
- Main principle
- Superheterodyne (common); ZF/IF 455/10700 kHz
- Wave bands
- Broadcast (BC) and FM or UHF.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 110 - 120 Volt
- Loudspeaker
- 6 Loudspeakers
- from Radiomuseum.org
- Model: MD1612 Ch= 12B - Curtis Mathes MfG. Co.;
- Notes
- AC operated AM - FM receiver with stereo output and 4 speed automatic record changer. Sams photofact set 484 folder 9 date 5-60 features the Curtis Mathes models MD712, MD912, MD1012, MD1412, MD1512, MD1612 and MD1712 as the same schematic.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 484 folder 9 date 5-60)
- Author
- Model page created by Peter Hoddow. See "Data change" for further contributors.
