AM/FM Radio Cassette Recorder ARC-130A

Daewoo Electronics (Daytron); Seoul

Data
Forum
Pictures
Collections

  • Year
  • 2000 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 290542

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Line / Batteries (any type) / 230 / R14: 4 x 1,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8.5 cm = 3.3 inch
  • Power out
  • 1 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: AM/FM Radio Cassette Recorder ARC-130A - Daewoo Electronics Daytron;
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 265 x 120 x 80 mm / 10.4 x 4.7 x 3.1 inch
  • Notes

  • DAEWOO AM/FM Portable Radio Cassette Recorder mod. ARC-130A - controllo volume - commutatore off/radio/tape - commutatore band AM/FM - uscita per cuffia - maniglia di trasporto - antenna telescopica esterna - automatic stop system - automatic level control - tasti pause/stop-eject/ff,wd/rew/play/rec - microfono incorporato - frequency range: FM 87,5-108 MHz - AM 530-1610 kHz - consumo 5 watt.

    Made in China.

  • Net weight (2.2 lb = 1 kg)
  • 0.7 kg / 1 lb 8.7 oz (1.542 lb)
  • Author
  • Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
