Digital Multimeter with audible alarm 936
Data Precision Corp.; Wakefield
- Country
- United States of America (USA)
- Manufacturer / Brand
- Data Precision Corp.; Wakefield
- Year
- 1980
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 310767
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 3
- Semiconductors
- 2N3906 GES5818 2N3906 TL062 CD4030 MC1403 ICL7106 A14U 1N4148 1N751 1N752 1N4744 unknown_Display
- Wave bands
- - without
- Power type and voltage
- Batteries / addl. power jack / PP3: 1 x 9 / 9 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Digital Multimeter with audible alarm 936 - Data Precision Corp.;
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 6.75 x 1.5 x 3.5 inch / 171 x 38 x 89 mm
- Notes
-
Hand held, pocket portable 3-1/2 digit. Similar to model 935 but with an audible alarm circuit.
- Net weight (2.2 lb = 1 kg)
- 0.270 kg / 0 lb 9.5 oz (0.595 lb)
- Mentioned in
- Funkschau (5/1980, S. 66)
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
