Pandora 6
Daxon Radio, Buenos Aires
- Country
- Argentina
- Manufacturer / Brand
- Daxon Radio, Buenos Aires
- Year
- 1948 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 165385
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 465 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- AC/DC-set / 110/220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm
- Power out
- 3 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Pandora 6 - Daxon Radio, Buenos Aires
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 370 x 260 x 220 mm / 14.6 x 10.2 x 8.7 inch
- Author
- Model page created by Heriberto Tavella. See "Data change" for further contributors.
- Other Models
-
Here you find 4 models, 2 with images and 0 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
