- Country
- Germany
- Manufacturer / Brand
- DEBEG, Deutsche Betriebsges.f.drahtlose Telegraphie mbH;
- Year
- 1979 ?
- Category
- Commercial Receiver (may include amateur bands)
- Radiomuseum.org ID
- 77979
-
- Brand: Deutsche Betr-ges.f.drahtl.Telegraphie mbH
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superhet, double/triple conversion; ZF/IF 38000/1400 kHz
- Wave bands
- Broadcast, Long Wave and more than two Short Wave bands.
- Power type and voltage
- Line / Batteries (any type) / 110; 220 / 24 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 3 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: 2000 - DEBEG, Deutsche Betriebsges.f.
- Shape
- Rack
- Dimensions (WHD)
- 502 x 173 x 420 mm / 19.8 x 6.8 x 16.5 inch
- Notes
- coverage 10 - 30000 kHz AM, SSB
digital readout 100 Hz, keypad direct frequency entry
29 memories, 500 and 2182 kHz fixed frequencies.
- Net weight (2.2 lb = 1 kg)
- 13.6 kg / 29 lb 15.3 oz (29.956 lb)
- Price in first year of sale
- 12,000.00 DM
- Source of data
- Shortwave Receivers - Past & Present (3rd ed.) / Radiokatalog Band 2, Ernst Erb
- Author
- Model page created by Martin Bösch. See "Data change" for further contributors.
