- Country
- United States of America (USA)
- Manufacturer / Brand
- Decca Records, Inc.; New York, NY
- Year
- 1959 ?
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 139281
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 2
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Rec.Player+Audio.Amp+LS
- Power type and voltage
- Alternating Current supply (AC) / 105 - 125 Volt
- Loudspeaker
- 2 Loudspeakers
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: DP-586 - Decca Records, Inc.; New York,
- Shape
- Tablemodel, with any shape - general.
- Notes
- AC operated stereo amplifier with 3 speed manual record player. Sams photofact set 508 folder 8 date 11-60 features the Decca models DP-584, DP-546, DP-586 and DPS-20 as the same schematic.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 508 folder 8 date 11-60)
- Author
- Model page created by Peter Hoddow. See "Data change" for further contributors.
