- Country
- Germany
- Manufacturer / Brand
- Delphin-Werk Helmut Kretschmar OHG, Pirna; (Ostd.)
- Year
- 1968 ??
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 83261
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 4
- Semiconductors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Rec.Player+Audio.Amp+LS
- Power type and voltage
- Alternating Current supply (AC) / 110, 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 2 W (unknown quality)
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: Pirett - Delphin-Werk Helmut Kretschmar
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 332 x 288 x 168 mm / 13.1 x 11.3 x 6.6 inch
- Notes
- 33/45 U/min, Reibrad, Kristallabtastsystem, Stereo mit Diodenausgang, Monowiedergabe über eingebauten Verstärker, 3-W-Lautsprecher im Deckel. - Weiterentwicklung des "Duett".
- Net weight (2.2 lb = 1 kg)
- 6 kg / 13 lb 3.5 oz (13.216 lb)
- Price in first year of sale
- 266.00 DM
- Source of data
- Radiokatalog Band 2, Ernst Erb
- Mentioned in
- -- Original prospect or advert
- Author
- Model page created by Wolfgang Lill. See "Data change" for further contributors.
