Precision audio component / AM-FM Stereo Tuner TU-235RD

Denon (Marke / brand)

Data
Forum
Pictures
Collections

  • Year
  • 1999
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 254235

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • PLL, Phase-locked loop
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 230 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Precision audio component / AM-FM Stereo Tuner TU-235RD - Denon Marke / brand
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 434 x 75 x 239 mm / 17.1 x 3 x 9.4 inch
  • Notes

  • A stereo hi-fi AM/FM tuner with a digital display. Optional remote control (RC-824). Automatic signal seek and manual tuning. 40 station preset memory. With RDS (Radio Data System) including RT (Radio Text), EON (Enhanced Other Networks), TA (Traffic Announcements), PS (Programme Service), PTY (Programme Type) and CT (Clock Time). Supplied with FM & AM indoor antennas. Sockets for FM coax in, AM loop antenna (spring clips) and 2 x phono sockets for audio output.

    Specifications
    FM Section
    Tuning frequency               87.50 - 108.00 MHz
    Usable sensitivity (DIN)      0.9 µV (10.3 dBf)
    Signal-to-noise ratio:          Mono 82 dB, Stereo: 76 dB (A-weighted)
    Total Harmonic Distortion:  Mono:0.5 %, Stereo: 0.8 %
    Frequency Response        20 Hz - 15 kHz (+0.5, -1.0 dB)
    Stereo Separation             40 dB (1 kHz)
    AM Section
    Tuning frequency              522 - 1611 kHz
    Usable Sensitivity            18 µV
    Signal-to-noise ratio         53 dB

    Similar to the Denon TU-260LII AM-FM Stereo Tuner which additionally has LW.

    R.D.S. EON, Radio Text; 40 Programmspeicherplätze; Fernbedienbar; Leistungsaufnahme 9 Watt.

    Made in Europe.

  • Net weight (2.2 lb = 1 kg)
  • 2.5 kg / 5 lb 8.1 oz (5.507 lb)
  • Source of data
  • -- Original prospect or advert
  • Mentioned in
  • -- Original prospect or advert (1999 Denon Product catalogue)
  • Literature/Schematics (1)
  • - - Manufacturers Literature (TU-235RD/260LII Operating Instructions)
  • Author
  • Model page created by Museum Roggenhofer. See "Data change" for further contributors.
