AV Surround Receiver AVR-3801

• Country
• Japan

• Manufacturer / Brand
• Denon (Marke / brand)

• Year
• 2004 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 316277

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• PLL, Phase-locked loop

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 50Hz, 230 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 140 W (undistorted)

• Material
• Metal case

• from Radiomuseum.org
• Model: AV Surround Receiver AVR-3801 - Denon Marke / brand

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 434 x 171 x 416 mm / 17.1 x 6.7 x 16.4 inch

• Notes

• - Power Amplifier 5.1 - 140 W ( front, Center, Surround y Surround Back )

  - Imput Audio / Video  / S-Video Analog : DVD, VCR1 , VCR2,, VDP, Tape, Phono, Aux

  - Imput Digital Coaxial

  - 3 Outputs Digital



• Net weight (2.2 lb = 1 kg)
• 17 kg / 37 lb 7.1 oz (37.445 lb)

• Author
• Model page created by Julián Muñoz Lorenzo. See "Data change" for further contributors.

• Other Models

• Here you find 473 models, 467 with images and 49 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
