PCM Audio Technology / Compact Disc Player DCD-1400

Denon (Marke / brand)

Data
Forum
Pictures
Collections

  • Year
  • 1988 ?
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 312579

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • CD-Player, -Writer, MD, MOD (audio); Remote Control (with wire or wireless)
  • Power type and voltage
  • Alternating Current supply (AC) / 100 or 120 or 220 or 240 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: PCM Audio Technology / Compact Disc Player DCD-1400 - Denon Marke / brand
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 434 x 112 x 314 mm / 17.1 x 4.4 x 12.4 inch
  • Notes

  • A stereo hi-fi compact disc player with remote control (RC-205). Super Linear Converter with independent left and right channel DACs and a four times oversampling digital filter, and an LC-OFC analogue filter. RCA sockets for fixed and variable line out, sockets for optical and digital output and a jack for headphones with a volume level control.

    Specification
    No. of channels:        2 channels
    Frequency response: 2 - 20,000 Hz
    Dynamic range:         96 dB
    Signal-to-noise ratio: 103 dB
    Harmonic distortion:   0.0035% (1 kHz)
    Separation:               100 dB (1 kHz)
    Output voltage:          2.0 V (Variable 0V — 2.0V)

    Functions:
    Direct selection, automatic search, programmed selection, repeat playback, call, auto edit.

    Display:
    Track number, index number, time, program and direct, etc.

    Versions/Power Requirement
    USA  /  120V AC 60Hz
    Canada  /  120V AC 60Hz
    Europe, UK  /  220/240V AC 50/60Hz
    Australia  /  240 V AC 50/60Hz
    Japan  /  100 V AC 50/60Hz
    Asia  / 120/220/240V AC 50/60Hz with voltage selector

  • Net weight (2.2 lb = 1 kg)
  • 6.3 kg / 13 lb 14 oz (13.877 lb)
  • Literature/Schematics (1)
  • - - Manufacturers Literature (Service Manual Stereo CD Player model DCD-1400)
  • Author
  • Model page created by Howard Craven. See "Data change" for further contributors.
